While many in the semiconductor industry are focused on AI chip innovations for the world’s nearly 12,000 data centers, the chips powering the world’s 20+ billion IoT devices are undergoing significant innovations as well. Below, the IoT Analytics team shares 6 predictions for how the IoT semiconductor space is changing in 2026, based on the following 3 recent market reports:

Prediction 1: Edge AI integration into IoT chips to accelerate

Edge AI integration into IoT devices will begin a major shift toward AI-capable hardware.
Most IoT devices today lack the built-in compute needed to run AI workloads. Even though demand for local inference has been rising to improve latency, resiliency, bandwidth efficiency, and privacy, the majority of today’s 21 billion deployed IoT endpoints still rely on external processing or simple rule-based logic. This gap between demand and capability sets the stage for a shift in 2026.

NPUs and AI-capable cores entering mainstream IoT designs

Vendors expanding edge AI across IoT tiers. In recent years, only a small subset of IoT products (typically industrial gateways, advanced cameras, and high-end modules) have integrated NPUs or low-power AI accelerators. Vendors are now starting to push these capabilities into broader device categories. New IoT SoCs are being designed with lightweight NPUs, vector extensions, and DSP-like AI cores to support tasks such as anomaly detection, small-model vision, local audio intelligence, and condition monitoring directly on the device.

Prediction: IoT Analytics expects 2026 to mark the first broad wave of IoT devices embedded with edge AI acceleration. Shipments of AI-enabled chipsets will expand into sensors, IoT connectivity modules, industrial PCs, and mid-tier gateways that previously lacked any on-device AI inference.

More complex SoC designs driving demand for AI-ready tooling.

AI features affecting IoT chip design priorities. Embedding NPUs and AI blocks into IoT silicon has increased design complexity, especially around thermal budgets, verification, memory bandwidth, and security. As a result, IoT chip vendors are leaning more heavily on EDA tools optimized for AI compute analysis, reusable IP such as low-power NPUs and secure enclaves, and mature-node foundry processes tuned for mixed workloads (compute + connectivity + security). These needs are emerging across consumer, industrial, automotive, and energy IoT segments.

Prediction: IoT Analytics expects 2026 to bring wider adoption of AI-aware EDA flows and off-the-shelf AI IP subsystems in IoT chip development. These tools and IP blocks will reduce design complexity and lower the barrier for adding small-model inference to mass-market IoT devices.

Edge AI becoming a defining differentiator for IoT OEMs

Device makers linking AI to feature innovation. As AI-capable hardware becomes more accessible, device makers are beginning to treat local inference as a competitive discriminator, enabling features such as privacy-preserving analytics in smart home devices, real-time defect detection in industrial sensors, or offline wake-word detection in consumer electronics.

Prediction: IoT Analytics expects 2026 to be the inflection point when IoT OEMs scale from early 2025 pilots to broad portfolio refreshes, marketed as Edge AI-enabled IoT devices. This shift will accelerate the move from basic telemetry devices to endpoints that support local inference for on-device decision-making.

Prediction 2: The share of chiplet-based and RISC-V-based IoT chips to increase

Modularity and RISC-V gained ground in IoT. Over the past 2 years, rising cost pressures, greater integration demands, and the need for more flexible architectures have influenced the design of IoT semiconductors. These trends have pushed vendors toward modular design approaches such as chiplets and toward open ISAs like RISC-V. As these trends continue, the foundations being laid now suggest a meaningful rise in both chiplet-based and RISC-V-based IoT chips in 2026.

Chiplets

Chiplets replacing monolithic SoCs in new designs. Industry activity in 2024–2025 indicates a clear move away from monolithic SoCs toward partitioned, modular designs. Chiplet architectures separate computing, memory, and I/O functions into smaller dies that can be produced on different process nodes and connected using high-bandwidth interfaces. This has reduced mask costs, improved yields, and enabled targeted upgrades without redesigning entire SoCs. Recent examples include Tenstorrent and BOS Semiconductors introducing Eagle-N, a chiplet-based AI accelerator for automotive systems, and Intel announcing a multi-node, chiplet-based SoC for software-defined vehicles.

Prediction: IoT Analytics expects chiplet adoption in IoT, automotive, and AI chipsets to expand significantly in 2026. Companies will move from early custom chiplet designs to broader use of standardized compute, connectivity, and security chiplets. This modular approach will reduce engineering effort, shorten development cycles, and lower non-recurring engineering costs for AI, automotive, and IoT SoCs.

RISC-V architecture

RISC-V enabling customized low-power IoT chips. RISC-V has accelerated quickly in IoT as vendors sought flexibility, lower licensing costs, and the ability to customize CPUs for specialized devices. Its open, modular ISA has allowed companies to build differentiated processors without relying on closed IP ecosystems. This has led to fast-growing experimentation and commercial deployments across wearables, microcontrollers, and low-power edge devices.

Prediction: IoT Analytics expects RISC-V adoption to expand further in 2026 across low-power IoT edge devices, edge AI processors, and automotive subsystems. Growth will be strongest in markets that prioritize supply-chain sovereignty and deeper architectural control to tailor CPU cores for specialized edge and automotive workloads.

Prediction 3: More IoT chips to be designed with carbon awareness in mind

RISC-V adoption surging across IoT segments. Sustainability requirements are becoming more concrete for semiconductor vendors as regulations such as the EU’s Corporate Sustainability Reporting Directive (CSRD) and rising customer expectations make carbon transparency unavoidable. Carbon tracking is increasingly treated as a core design constraint in IoT, now discussed alongside power, performance, area, and cost (PPAC) rather than as a separate reporting exercise.

Design workflows integrating carbon metrics

Carbon metrics part of semiconductor design workflows. Several developments over 2024–2025 indicate that carbon data is starting to enter day-to-day engineering workflows. Some EDA vendors are already feeding emissions data into early architectural trade-offs. For example, in May 2025, US-based EDA, hardware, and IP provider  Cadence joined Belgian-based nanoelectronics R&D hub imec’s Sustainable Semiconductor Technologies and Systems (SSTS) program to integrate process and supply-chain emissions data directly into design environments, enabling engineers to compare carbon impacts the same way they compare power, performance, and area (PPA) metrics. IP providers are also expanding their deliverables to include sustainability metadata and lifecycle assumptions so that integrators can pass carbon estimates through system-level simulations and procurement stages.

Prediction: IoT Analytics expects carbon metrics to become more broadly integrated into IoT semiconductor design workflows in 2026. EDA and IP vendors will incorporate emissions data into the same early-stage evaluations used for PPAC, enabling engineers to include carbon impact in routine architectural trade-offs.

Foundries and chip vendors standardizing disclosures

IoT chipmakers improving carbon reporting standards. Foundries and chip suppliers in general have been increasing the granularity of their sustainability reporting, making it easier for OEMs to incorporate carbon impact into component selection. With IoT Analytics forecasting 39 billion connected IoT devices by the end of 2030, accurately capturing sustainability reporting details has become particularly important for the entire IoT ecosystem, and IoT semiconductor firms are already taking action.

In June 2024, Germany-based semiconductor design and manufacturing company Infineon expanded Product Carbon Footprint disclosures across MCUs and connectivity parts, covering materials, manufacturing, and logistics so OEMs can benchmark embodied carbon during evaluation, not just energy efficiency in operation. In April 2025, Taiwan-based contract chip manufacturer TSMC committed to the Science Based Targets initiative (or SBTi) and now provides node-level footprint data, while also pushing renewable sourcing across its supplier base.

Prediction: IoT Analytics expects 2026 to accelerate the shift toward standardized, auditable carbon disclosures from major foundries and IoT chip vendors. Chipset companies will shift from fragmented sustainability reports to structured product-level and node-level disclosures that feed directly into OEM sourcing tools. This lets procurement teams compare embodied carbon alongside price, performance, and qualification data, making carbon-aware component selection a routine part of IoT design.

Prediction 4: More IoT devices to be produced locally

Countries investing in local semiconductor manufacturing across the IoT value chain. Governments have intensified efforts to localize production of semiconductors in general as part of broader strategies to secure technology supply chains and reduce geopolitical risk. Export controls, sovereignty initiatives, and national subsidy programs have made localization a priority not only for advanced computing but increasingly for the lower-power, high-volume chips used in IoT devices. These point toward a 2026 environment in which a greater share of IoT chips will be fabricated, packaged, and assembled within regional ecosystems rather than concentrated in a single geography.

Policy pressure expanding into IoT components

Governments tighten control on semiconductor supplies, including IoT chips. National semiconductor policies initially focused on leading-edge logic, but recent actions indicate that governments are extending oversight into microcontrollers, connectivity chipsets, secure elements, and sensor-level silicon, key building blocks of IoT devices. The US, EU, China, and Japan have each updated their export-control lists and industrial policy frameworks to include categories relevant to IoT (e.g., RF front-end components, power management ICs [PMICs], and low-power MCUs). These moves signal that IoT silicon is no longer viewed as purely commoditized but as critical to national digital infrastructure.

Prediction: IoT Analytics expects 2026 to bring more regulation that explicitly targets IoT-grade semiconductors. These measures will shape both design and sourcing decisions for IoT modules, gateways, and endpoint devices by adding security certification requirements, local-content targets, and stricter reporting obligations for deployments in critical infrastructure and industrial environments.

Investments creating regional capacity for IoT-focused production

Countries investing in domestic IoT chip production. The last several years have seen large-scale industrial programs funding domestic manufacturing capacity. Notable examples include the following:

• US – The CHIPS and Science Act allocated $52.7 billion to boost domestic manufacturing and R&D. Further, the government has expanded funding to semiconductor production companies like Intel, TSMC, and Samsung.
• China – China hascountered the US’s actions with a $47.5 billion “Big Fund” to boost domestic chipmaking and close its technology gap by 2030.
• Japan – The government of Japan has committed approximately $65 billion by 2030 to expand its semiconductor and AI sectors, supporting domestic fabs and R&D partnerships.
• South Korea – Republic of Korea officials announced a $19 billion support package in 2024 to strengthen its chip supply chain and SME competitiveness.
• EU – The EU is channeling investments under the EU Chips Act to localize production, secure raw materials, and establish technological sovereignty across member states. Leading national efforts include Italy’s €10 billion investment to become one of the largest microelectronics producers in Europe and the Netherlands’ €2.5 billion Brainport Eindhoven initiative, which aims to enhance collaboration between businesses, academia, and governments for technological development, including semiconductors.

Prediction: IoT Analytics expects that by 2026, a number of new and expanded domestic and regional fabs focused on IoT-relevant semiconductor processes (e.g., mature-node logic, analog, embedded non-volatile memory, and RF) will begin production or ramp toward commercially meaningful volumes. As this capacity comes online in the coming years, it strengthens the ability of chipset vendors and countries to build more self-reliant regional supply chains for core IoT components.

Prediction 5: IoT chip design to become heavily AI-supported

AI becoming core part of IoT chip design workflows. EDA vendors have spent the past 2 years integrating AI into front-end and back-end design flows, giving semiconductor teams new ways to automate labor-intensive tasks, validate constraints, and identify issues earlier. These capabilities are especially relevant to IoT chips, where tight power, area, and cost envelopes leave little room for design iteration.

AI entering mainstream EDA workflows

AI expanding into full semiconductor design flows. Several developments across 2024–2025 show that AI is starting to assist with full design-flow activities rather than isolated point tools. In July 2025, Siemens Digital Industries Software, a US-based business unit of Germany-based industrial automation company Siemens, unveiled an AI-enhanced toolset covering schematic capture through physical implementation, including features for verification automation, constraint analysis, and early flaw detection. These tools are being positioned to support both semiconductor and PCB design, which is directly relevant to IoT vendors integrating RF, sensors, and compute into constrained form factors.

Prediction: IoT Analytics expects wider adoption of AI-assisted verification, constraint checking, and layout optimization in 2026, particularly within IoT design teams building edge-AI chipsets, connectivity SoCs, and mixed-signal devices. As these AI-enabled EDA workflows mature, they help teams shorten iteration cycles, reduce implementation errors, and manage the growing complexity of RF, sensor, and compute integration in compact IoT form factors.

Agentic AI moving toward workflow automation

EDA firms mapping path to autonomous design agents. Vendors are also outlining roadmaps for AI systems that do more than generate code or propose optimizations. In March 2025, US-based EDA software company Synopsys’ CEO Sassine Ghazi, for example, outlined a roadmap (shown below) in which today’s generative AI design tools will advance to fully autonomous, multi-agent design systems. These “agent engineers” are expected to support areas such as IP integration, advanced packaging, process-node selection, and lifecycle management, domains that directly affect IoT silicon, which increasingly mixes digital logic, RF, power management, and sensing functions in a single package.

Prediction: IoT Analytics expects early forms of agentic AI to enter IoT chip development workflows in 2026, mainly as workflow copilots that orchestrate existing EDA tools for tasks such as verification, IP integration, and physical design exploration. These systems automate routine steps, propose constraint and floorplan alternatives, and manage multi-tool design flows, while human engineers retain control over architectural choices, sign-off decisions, and safety-critical validation.

Prediction 6: IoT security-by-design to become non-negotiable

IoT security-by-design becoming requirement across global markets. Security-by-design has shifted from a best practice to a regulatory expectation, and this shift is especially consequential for IoT. IoT devices operate in widely distributed, resource-constrained environments (e.g., factories, homes, vehicles, and energy systems) where they cannot rely on traditional perimeter security. Their long lifecycles, remote deployment, and constant connectivity make hardware-level protection essential for safety, reliability, and compliance. These realities are pushing vendors to integrate stronger silicon-level security into the IoT value chain.

Hardware security becoming mandatory for market access

Compliance mandates evolving IoT security architectures. Regulatory frameworks such as the EU Cyber Resilience Act, the US National Institute of Standards and Technology’s (NIST) post-quantum roadmap, and UNECE R.155 and R.156 increasingly require verifiable hardware protections before devices can be sold. For IoT suppliers, this means that features such as hardware root of trust, secure boot, and physical unclonable function (PUF)-based identity are no longer optional; they are now prerequisites for certification in sectors such as industrial automation, automotive, healthcare, and smart home.

Prediction: IoT Analytics expects 2026 to bring broader adoption of hardware-enforced security baselines across high-end IoT MCUs, connectivity chipsets, secure elements, and edge-AI processors. As regulatory requirements tighten, silicon-level protections such as hardware root of trust, secure boot, and tamper-resistant identity will become standard entry conditions for critical and premium IoT markets. In lower-cost IoT devices, adoption will remain focused on lighter software-based measures such as secure boot and secure operating system support rather than full hardware-backed security.

Compliance ecosystems expanding to support IoT deployments

Vendors building tools for long-term IoT compliance. As requirements tighten, vendors are redesigning chip architectures and investing in compliance tooling that helps IoT device manufacturers meet lifecycle obligations. Companies such as UK-based IoT cybersecurity company Crypto Quantique are automating secure provisioning, certificate lifecycle management, and vulnerability tracking, capabilities IoT OEMs rely on because devices may be deployed for 10–20 years without physical access. Meanwhile, US-based semiconductor design and manufacturing company Qualcomm and others are standardizing secure boot flows, producing signed software bills of materials, and integrating monitoring mechanisms to help vendors maintain long-term compliance across deployed fleets.

Prediction: IoT Analytics expects 2026 to see growing adoption of end-to-end compliance ecosystems that support secure provisioning, certificate management, software bill-of-materials upkeep, and vulnerability monitoring across the full device lifecycle. IoT OEMs in regulated industrial, medical, and automotive markets increasingly combine internal security capabilities with external compliance-as-a-service platforms to meet long-term regulatory obligations without building all tooling in-house.

Global legislation, including the European Union’s proposed Cyber Resilience Act, necessitates platform-based security solutions to help prevent product engineering delays and/or significantly increased costs. Security is not a bolt-on module; it needs to be considered through the entire life-cycle of a product from initial hardware and software design to end of life.”

George Grey, VP software at Qualcomm (source)

Post-quantum readiness becoming a design constraint for long-lifecycle IoT

Post-quantum cryptography moving into IoT hardware. Quantum computing has elevated the urgency around post-quantum cryptography, particularly for IoT devices that will operate for decades and cannot easily be replaced. NIST’s guidance on migrating to post-quantum cryptography (PQC) by 2035 has led semiconductor vendors to embed quantum-safe algorithms (such as the Module-Lattice-Based Key-Encapsulation Mechanism (ML-KEM) into hardware. Infineon’s EAL6-certified PQC hardware (TEGRION security controllers) illustrates how quickly these features are moving from roadmap concepts to commercial products.

Prediction: IoT Analytics expects 2026 to bring early pilots of PQC–ready security blocks in higher-value IoT chips, driven by long-lifecycle requirements in sectors such as energy infrastructure, industrial automation, automotive gateways, and connected medical devices. Adoption remains limited to premium devices, but PQC should become a prominent design consideration as vendors begin preparing for NIST’s 2035 migration timeline.
